Description
The VitroView™ Colloidal Iron Stain Kit is intended for the histological demonstration of acidic mucopolysaccharides and mucins in tissue sections. The staining procedure yields clear, contrasting coloration of mucin-containing structures, supporting morphological identification and evaluation via light microscopy.
This kit is optimized for use with well-fixed, paraffin-embedded tissue sections. It is applicable to routine histopathological diagnostics and biomedical research applications that require the identification of acidic mucins.
Key Kit Features
- High Versatility: Compatible with any properly fixed, paraffin-embedded tissue samples.
- Sharp Contrast: Delivers bright blue staining against a clean background for easy evaluation.
- Reliable Results: Streamlined protocol ensures consistent and reproducible staining runs.
Kit Components
| SKU# | Reagent | Size (ml) |
| VB-3027-1 | Acetic Acid Solution (12%) | 500 |
| VB-3027-2 | Hydrochloric Acid Solution (3%) | 125 |
| VB-3027-3 | Potassium Ferrocyanide Solution (3%) | 125 |
| VB-3027-4 | Colloidal Iron Stock Solution | 125 |
| VB-3027-5 | Van Gieson’s Solution | 125 |
Storage
Store at room temperature
Protocol
Thing to do before staining
- Working Colloidal Iron Solution.
- Acetic Acid Solution (12%) —————5 ml
- Distilled Water ——————————-15 ml
- Colloidal Iron Stock Solution———– 20 ml
Mix well.
- Working Iron Stain Solution
- Hydrochloric Acid Solution (3%) ——–20 ml
- Potassium Ferrocyanide Solution——- 20 ml
Mix well
Procedures
- Deparaffinize in xylene I for 6 minutes and II for 6 minutes.
- Rehydrate
- Ethanol 100% (1 minutes)
- Ethanol 100% (1 minutes)
- Ethanol 95% (1 minutes)
- Ethanol 95% (1 minutes)
- Ethanol 70% (1 minutes)
- Rinse in DI water (2 minutes).
- Cover tissue section with Acetic Acid Solution (12%) for 30 seconds.
- Place slide in Working Colloidal Iron Solution for 30 minutes with occasional gentle agitation. Use once and discard.
- Rinse thoroughly in 3 changes of Acetic Acid Solution (12%) for 2 minutes each.
- Stain slide in Working Iron Stain Solution for 10 minutes with occasional gentle agitation. Use once and discard.
- Rinse in 3 changes of distilled water.
- Stain tissue section with Van Gieson’s Solution for 30 seconds.
- Dehydrate in 3 changes of absolute alcohol.
- Clear with 3 changes of xylene (5 minute per change)
- Mount coverslip onto glass slide with Permount or some other suitable organic mounting medium.
Expected Results
- Acid mucopolysaccharides and sialomucins——–deep blue
- Collagen———————————————————red
Control Tissue
Large airway, Small intestine or Colon.
More Images







Note
This product is intended for research purposes only. This product is not intended to be used for therapeutic or diagnostic purposes in humans or animals.
Precautions
Handle with care. Avoid contact with eyes, skin and clothing. Do not ingest. Wear gloves.
User Manual and Material Safety Data Sheet (MSDS) (PDF)
Frequently Asked Questions
What does this kit demonstrate?
Carboxylated and sulfated mucopolysaccharides and glycoproteins in tissue. Colloidal ferric ions are absorbed principally by carboxylated and sulfated mucosubstances at low pH, and the classic Prussian blue reaction is used to demonstrate the iron bound to the tissue. Acid mucopolysaccharides and sialomucins stain deep blue, and collagen stains red.
What sample types can I use it on?
It is suitable for any well-fixed, paraffin-embedded tissue.
What is in the kit?
Five reagents: Acetic Acid Solution, 12% (VB-3027-1), 500 ml; Hydrochloric Acid Solution, 3% (VB-3027-2), 125 ml; Potassium Ferrocyanide Solution, 3% (VB-3027-3), 125 ml; Colloidal Iron Stock Solution (VB-3027-4), 125 ml; and Van Gieson’s Solution (VB-3027-5), 125 ml.
How should I store it?
At room temperature.
What do I need to prepare before staining?
Two working solutions must be prepared fresh before staining: the Working Colloidal Iron Solution (5 ml Acetic Acid Solution 12%, 15 ml distilled water, 20 ml Colloidal Iron Stock Solution) and the Working Iron Stain Solution (20 ml Hydrochloric Acid Solution 3% and 20 ml Potassium Ferrocyanide Solution). Each working solution is used once and discarded.
What are the key steps in the protocol?
After deparaffinizing in xylene and rehydrating through graded ethanols, sections are covered with Acetic Acid Solution (12%) for 30 seconds, placed in the Working Colloidal Iron Solution for 30 minutes, rinsed in Acetic Acid Solution, stained in the Working Iron Stain Solution for 10 minutes, rinsed, and stained with Van Gieson’s Solution for 30 seconds, then dehydrated, cleared in xylene, and mounted with Permount or another suitable organic mounting medium. The recommended control tissue is skin, small intestine, or colon.
